Description
* RO Filtration System *
• HW-UP100 : Sediment Filter + Pre Carbon Filter RO Membrane Filter + Post Carbon Filter
• HW-UP100M : Sediment Filter + Pre Carbon Filter RO Membrane Filter + Post Carbon Filter + RO Pump
* Optional Filter System (UF membrane / Alkali / Nano pH)
• HW-UP(OP)200 A : Sediment Filter + Pre Carbon Filter + UF Membrane Filter + Alkali Filter + Post Carbon Filter
• HW-UP(OP)200 N : Sediment Filter + Pre Carbon Filter + Nano pH Filter + Post Carbon Filter
• HW-UP(OP)200 U : Sediment Filter + Pre Carbon Filter + UF Membrane Filter + Post Carbon Filter
* Tankless RO System *
• HW-UP(OP)300 M : Sediment Filter + Pre Carbon Filter + RO Membrane Filter + Post Carbon Filter + RO Pump
1. Features of HW-UP 100 Series
♦ Undersink type
♦ Use of RO membrane Filter
– Average Flow Rate(GPD): 50,75,100,150 GPD
– Improving the TDS(Total Dissolved Solids) rejection
– Meets all different water quality needs.
♦ With booster pump (HW-UP 100M)
– Using the high quality booster pump that can provide 100-120psi water pressure to pass through
the membrane even with areas under low water pressure.
♦ Specification
– Dimension : 325*180*430mm(W*D*H)
– Weight : 7.5kgs (HW-UP 100), 9.5kgs (HW-UP 100M)
2. Features of HW-UP(OP) 200 Series
♦ Undersink type & Onsink type(Counter top)
♦ Saving space
♦ Optional Filter System(UF membrane / Alkali / Nano pH)
* UF membrane Filter – Removal for harmful chemicals, bacteria, virus, Etc. But, containing the minerals beneficial for health
* Alkali Filter – Removal Active Oxygen(pH5.8~pH8.2)
* Nano Ph Filter – Strong of oxidation, reduction potential reducing rate Removal Active Oxygen(Ph8~Ph10)
♦ Specification
– Dimension : 325*180*430mm(W*D*H)
– Weight : 7.5kgs
3. Features of HW-UP 300 Series
♦ Tankless Reverse Osmosis System
♦ Undersink type & Onsink type(Counter top)
♦ Use of RO 300 GPD Filter
– Average Flow Rate(GPD): 300 GPD
– Improving the TDS(Total Dissolved Solids) rejection(Rejection Rate: 97%)
– Meet all different water quality needs.
♦ With booster pump(Motor)
– Using the high quality booster pump that can provide 100-120psi water pressure to pass through the
membrane even with areas under low water pressure.
♦ Basic permeate rate
– Inlet water oressure : 3kgf/cm²- Flow rate : 120LPH / Capacity of treated water : 300 GPD
♦ Specification
– Dimension : 325*180*430mm(W*D*H)
– Weight : 10.5kgs
